СИДЕНИЕ И ОПОРА СИДЕНЬЯ на Bobcat 500s Bobcat 540 501012001 И ВЫШЕ

1: Артикул: SEAT, SEAT See Illustration SEAT/ B7185 NLA - Was 6563140 - A
2: Артикул: SEAT, SEAT BELT NLA - Order Ref. 32 - Was 6564774 - A
3: Артикул: SEAT, SEAT BELT NLA - Order 6675074 Seat Belt - Was 6667875 - A
4: Артикул: SEAT, SEAT BELT NLA - W/Spring Plates - Order 6675074 Seat Belt & (2) of Ref. 3 (6725373 Spring Plate) - Was 6725403 - A

Условия поставки:

Цена по запросу

Склад в СПб

Запчасти в наличии

Выездной сервис

Доставка тралом

О модели СИДЕНИЕ И ОПОРА СИДЕНЬЯ

СИДЕНИЕ И ОПОРА СИДЕНЬЯ на Bobcat 500s Bobcat 540 501012001 И ВЫШЕ

Техническая спецификация:

Габаритные размеры:

Технические характеристики: СИДЕНИЕ И ОПОРА СИДЕНЬЯ

1	Артикул: SEAT, SEAT See Illustration SEAT/ B7185 NLA - Was 6563140 - A
2	Артикул: SEAT, SEAT BELT NLA - Order Ref. 32 - Was 6564774 - A
3	Артикул: SEAT, SEAT BELT NLA - Order 6675074 Seat Belt - Was 6667875 - A
4	Артикул: SEAT, SEAT BELT NLA - W/Spring Plates - Order 6675074 Seat Belt & (2) of Ref. 3 (6725373 Spring Plate) - Was 6725403 - A
5	Артикул: 6675074, SEAT BELT W/O spring plates
6	Артикул: GUIDE, GUIDE ASSY. NLA - 13.75-- (349,3 mm) - Use W/Ref. 2 (NLA/6564774 Seat Belt) - Was 6565354 - A
7	Артикул: GUIDE, GUIDE ASSY. NLA - W/Ref. 5 & 6 - 12.25-- (311,2 mm) - Use W/Ref. 2 (6667875 Selt Belt) - Order 6711908 Spring Plate, Ref. 5 & (2) of Ref. 6 - Was 6711907 - A
8	Артикул: 6711908, SPRING PLATE Use W/Ref. 2 (NLA/6667875 Seat Belt)
9	Артикул: 6725373, SPRING PLATE Use W/Ref. 2 (6675074 seal belt)
10	Артикул: GUIDE, GUIDE NLA - Order 6703703 - Was 6565355
11	Артикул: 6630207, RIVET 5 Was 6512797 - A
12	Артикул: 6564506, WASHER
13	Артикул: 17C716, BOLT
14	Артикул: 61D7, NUT
15	Артикул: 4E5, WASHER Was 4E000006B - B
16	Артикул: 61D5, NUT Was 61D000006B - B
17	Артикул: ARM, ARM NLA - L.H. - Order Ref. 29 - Was 6563296 - A
18	Артикул: ARM, ARM NLA - R.H. - Order Ref. 29 - Was 6563295 - A
19	Артикул: 84G3712, BOLT 5
20	Артикул: SEAT, SEAT BAR NLA - Order Ref. 29 - Was 6563095 - A
21	Артикул: 83D6, NUT 5
22	Артикул: 6563557, WASHER
23	Артикул: 6563313, RETAINER
24	Артикул: 6704453, SPRING Was 6503387 - A
25	Артикул: BUSHING, BUSHING NLA - Order Ref. 6 & 30 - Was 6568742 - A
26	Артикул: 17C636, BOLT
27	Артикул: 6563148, BLOCK, SPRING
28	Артикул: 14J2512, PIN 5
29	Артикул: 6702430, SPRING, COMPRESSION Was 6563149 - C
30	Артикул: 6563150, LOCK
31	Артикул: 17C612, BOLT 5
32	Артикул: 6700170, WASHER nylon - Was 6563152 - A
33	Артикул: 6559479, NUT
34	Артикул: 17C616, BOLT 5
35	Артикул: 6563151, LINK
36	Артикул: 6706324, SEAT BAR 1 piece - Was 6703301 - A
37	Артикул: 6564507, BUSHING
38	Артикул: 6706796, KIT See Illustration SEAT BAR KIT/ C3341 gas spring seat bar
39	Артикул: KIT, KIT NLA - W/Ref. 2 & 3 - Order Ref. 2 (6725403 Seat Belt) - Was 6713061 - A
