СИДЕНИЕ И ОПОРА СИДЕНЬЯ

Лизинг от 0% первого взноса Заводская гарантия ЭПСМ готов

СИДЕНИЕ И ОПОРА СИДЕНЬЯ на Bobcat 800s Bobcat 853 508411001 - 508414999, 509711001 - 509714999

1: Артикул: SEAT, SEAT See Illustration SEAT/ B7185
2: Артикул: SEAT, SEAT BELT NLA - Order Ref. 33 - Was 6564774 - A
3: Артикул: SEAT, SEAT BELT NLA - W/ Spring Plates - Order 6675074 Seat Belt & (2) Of Ref. 3 (6725373 Spring Plate) - Was 6667875 - A
4: Артикул: SEAT, SEAT BELT NLA - W/ Spring Plates - Order 6675074 Seat Belt & (2) Of Ref. 3 (6725373 Spring Plate) - Was 6725403 - A

Условия поставки:

Цена по запросу

Склад в СПб

Запчасти в наличии

Выездной сервис

Доставка тралом

О модели СИДЕНИЕ И ОПОРА СИДЕНЬЯ

СИДЕНИЕ И ОПОРА СИДЕНЬЯ на Bobcat 800s Bobcat 853 508411001 - 508414999, 509711001 - 509714999

Техническая спецификация:

Габаритные размеры:

Технические характеристики: СИДЕНИЕ И ОПОРА СИДЕНЬЯ

1	Артикул: SEAT, SEAT See Illustration SEAT/ B7185
2	Артикул: SEAT, SEAT BELT NLA - Order Ref. 33 - Was 6564774 - A
3	Артикул: SEAT, SEAT BELT NLA - W/ Spring Plates - Order 6675074 Seat Belt & (2) Of Ref. 3 (6725373 Spring Plate) - Was 6667875 - A
4	Артикул: SEAT, SEAT BELT NLA - W/ Spring Plates - Order 6675074 Seat Belt & (2) Of Ref. 3 (6725373 Spring Plate) - Was 6725403 - A
5	Артикул: 6675074, SEAT BELT W/O spring plates
6	Артикул: GUIDE, GUIDE ASSY. NLA - W/Ref. 4 & 5 - 13.75 in. Used W/ NLA/6564774 - Was 6565354 - A
7	Артикул: GUIDE, GUIDE ASSY. NLA - W/Ref. 4 & 5 - 12.25 in. Use W/ (NLA/6667875) Seat Belt - Order 6711908 Spring Plate, Ref. 4 & (2) Of Ref. 5 - Was 6711907 - A
8	Артикул: 6711908, SPRING PLATE Use W/Ref. 2 (NLA/6667875 Seat Belt)
9	Артикул: 6725373, SPRING PLATE Use W/Ref. 2 (6675074 seal belt)
10	Артикул: GUIDE, GUIDE NLA - Order 6703703 - Was 6565355
11	Артикул: 6630207, RIVET 5 Was 6512797 - A
12	Артикул: 85D6, NUT, 5
13	Артикул: 17C716, BOLT
14	Артикул: 85D7, NUT
15	Артикул: 4E5, WASHER
16	Артикул: 61D5, NUT
17	Артикул: 6706324, SEAT BAR one piece - Was 6703301 - A
18	Артикул: 6568742, BUSHING
19	Артикул: 35C608, BOLT
20	Артикул: 83D6, NUT 5
21	Артикул: 6563557, WASHER
22	Артикул: 6563313, RETAINER
23	Артикул: 6704453, SPRING Was 6578252 - A
24	Артикул: 6563151, LINK
25	Артикул: 17C616, BOLT 5
26	Артикул: 6563148, BLOCK, SPRING
27	Артикул: 14J2512, PIN 5
28	Артикул: 6702430, SPRING, COMPRESSION Was 6563149 - A
29	Артикул: 6578150, LOCK
30	Артикул: 84G3712, BOLT 5
31	Артикул: 6700170, WASHER nylon - Was 65700170 - A
32	Артикул: 6559479, NUT
33	Артикул: 6705489, BOLT Was 84G003724B - A
34	Артикул: 6705474, LOCK SHIELD Never operate loader without pedal lock shield on both interlocks ... SEE WARNING ON PREVIOUS PAGE
35	Артикул: 6705720, DECAL Was 6705488 - A
36	Артикул: 59D6, NUT NUT
37	Артикул: 6722392, INSTRUCTIONS for Ref. 28
38	Артикул: 6706796, KIT See Illustration SEAT BAR KIT/ C3341 - gas spring seat bar
39	Артикул: KIT, KIT NLA - W/Ref. 2 & 3 - Order Ref. 2 (6675074 Seat Belt) & (2) Of Ref. 3 (6725373 Spring Plate) - Was 6713061 - A
