НАКЛЕЙКИ на Bobcat 800s Bobcat 873 514111001 - 514139999, 514211001 - 514239999

1: Артикул: 6900505, KIT decal
2: Артикул: 6715610AR, KIT translation - SEE NOTE
3: Артикул: 6715610BR, KIT translation - SEE NOTE
4: Артикул: 6715612AR, KIT decal - SEE NOTE

Условия поставки:

Цена по запросу

Склад в СПб

Запчасти в наличии

Выездной сервис

Доставка тралом

О модели НАКЛЕЙКИ

НАКЛЕЙКИ на Bobcat 800s Bobcat 873 514111001 - 514139999, 514211001 - 514239999

Техническая спецификация:

Габаритные размеры:

Технические характеристики: НАКЛЕЙКИ

1	Артикул: 6900505, KIT decal
2	Артикул: 6715610AR, KIT translation - SEE NOTE
3	Артикул: 6715610BR, KIT translation - SEE NOTE
4	Артикул: 6715612AR, KIT decal - SEE NOTE
5	Артикул: 6715612BR, KIT decal - SEE NOTE
6	Артикул: 6715612JP, KIT decal - SEE NOTE
7	Артикул: 6560573, DECAL spark arrestor - Was 6708937 - A
8	Артикул: 6708820, DECAL lift arm stop
9	Артикул: 6577754, DECAL, WARNING 5 gas spring
10	Артикул: 6578368, DECAL, OPERATION push to release stop
11	Артикул: 6703645, DECAL R.H. - Bobcat head - for black lift arm
12	Артикул: 6557412, DECAL RH - Bobcat head - white lift arms - 193 x 424,2 mm (7.6 x 16.7--) - not in kit
13	Артикул: 6703646, DECAL L.H. - Bobcat head - for black lift arm
14	Артикул: 6557413, DECAL LH - Bobcat head - white lift arms - 193 x 424,2 mm (7.6 x 16.7--) - not in kit
15	Артикул: 6727309, DECAL, LOGO RH R.H. Bobcat & head - 10-- x 20-- - Was 6702826 - A
16	Артикул: 6727308, DECAL, LOGO BOBCAT LH - W/Bobcat head - 20-- x 10-- (508 mm x 254 mm) - Was 6702827 - A
17	Артикул: 6708941, DECAL, WARNING rotating parts
18	Артикул: 6708257, DECAL model no. R.H.
19	Артикул: 6715991, DECAL fuse - Was 6707786 - A
20	Артикул: 6727595, DECAL See Illustration DECALS/ B18463 Was 6595014 - B
21	Артикул: DECAL, DECAL NLA - filters - Order Ref. 14 - Was 6708936 - A
22	Артикул: DECAL, DECAL NLA - warning - Order Ref. 14 - Was 6579511 - A
23	Артикул: DECAL, DECAL NLA - tow hook - Order Ref. 10 - Was 6707867 - A
24	Артикул: DECAL, DECAL NLA - service - Order 6734534 - Was 6710457 - A
25	Артикул: 6734534, DECAL, SERVICE service/warning/filters - Was 6718398 - A
26	Артикул: DECAL, DECAL NLA - Bobcat Logo - two piece door - 9-- (229mm) x 22.75 (578mm ) - Was 6727307 - A
27	Артикул: DECAL, DECAL NLA - Logo - one piece door 10.3-- (262mm) x 28.5 (723mm) - Was 6727311 - A
28	Артикул: 6708929, DECAL, COOLANT propylene glycol
29	Артикул: 6707787, DECAL See Illustration ENGINE ELECTRICAL CIRCUITRY/ B18415 See Illustration ENGINE ELECTRICAL CIRCUITRY/ B18413 RELAY
30	Артикул: 6731475, DECAL model - Was 6714538 - A
31	Артикул: 6727912, DECAL turbo - for one piece door - Was 6714526 - A
32	Артикул: 6714242, DECAL tailgate - for one piece door
33	Артикул: 6718272, DECAL Advantage Series - R.H. - not in kit
