МАГНЕТО

Лизинг от 0% первого взноса Заводская гарантия ЭПСМ готов

МАГНЕТО на Bobcat 400s Bobcat 444M 1001 И ВЫШЕ

1: Артикул: MAGNETO, MAGNETO ASSY. NLA - Ref. 2 - 34, 36 - 57, 59 & 60 - Was 6517352 - A
2: Артикул: SCREW, SCREW NSS - window clamp plate
3: Артикул: PLATE, PLATE NSS - window clamp
4: Артикул: GASKET, GASKET NSS - cap window sealing

Условия поставки:

Цена по запросу

Склад в СПб

Запчасти в наличии

Выездной сервис

Доставка тралом

О модели МАГНЕТО

МАГНЕТО на Bobcat 400s Bobcat 444M 1001 И ВЫШЕ

Техническая спецификация:

Габаритные размеры:

Технические характеристики: МАГНЕТО

1	Артикул: MAGNETO, MAGNETO ASSY. NLA - Ref. 2 - 34, 36 - 57, 59 & 60 - Was 6517352 - A
2	Артикул: SCREW, SCREW NSS - window clamp plate
3	Артикул: PLATE, PLATE NSS - window clamp
4	Артикул: GASKET, GASKET NSS - cap window sealing
5	Артикул: WINDOW, WINDOW NSS - distributor cap
6	Артикул: SCREW, SCREW NSS - distributor cap
7	Артикул: 6517362, CAP distributor - W/Ref. 2-5
8	Артикул: 6517363, COIL core sold separately
9	Артикул: COIL, COIL NLA - contact - Was 6517364 - A
10	Артикул: 6517365, CONDENSER
11	Артикул: 6517366, BREAKER contact set
12	Артикул: GEAR, GEAR NSS - pinion - Was 6517367 - A
13	Артикул: SCREW, SCREW NLA - pinion gear
14	Артикул: SCREW, SCREW NSS - breaker contact-Was 6517369 - A
15	Артикул: SCREW, SCREW NLA - breaker spring clamp
16	Артикул: FELT, FELT NLA - breaker arm
17	Артикул: CLAMP, CLAMP NLA - condenser
18	Артикул: CLAMP, CLAMP NLA - coil core
19	Артикул: SCREW, SCREW NLA - coil core clamp & condensor clamp
20	Артикул: CORE, CORE NSS - coil - Was 6517375 - A
21	Артикул: FELT, FELT NLA - cam wiper
22	Артикул: WASHER, WASHER NLA - breaker point aligning screw
23	Артикул: WASHER, WASHER NLA - breaker screw
24	Артикул: WASHER, WASHER NLA - breaker arm pivot
25	Артикул: RETAINER, RETAINER NLA - breaker arm
26	Артикул: PIVOT, PIVOT NLA - breaker arm
27	Артикул: 6517382, ROTOR distributor
28	Артикул: 6667994, GASKET distributor cap - Was NSS - A
29	Артикул: BUTTON, BUTTON NSS - stop
30	Артикул: NUT, NUT NSS - ground stud
31	Артикул: WASHER, WASHER NSS - lock - ground stud
32	Артикул: WASHER, WASHER NSS - ground stud
33	Артикул: INSULATOR, INSULATOR NSS - ground stud
34	Артикул: WASHER, WASHER NSS - insulated - ground stud
35	Артикул: GROUND, GROUND NSS - lead
36	Артикул: SCREW, SCREW NSS - ground
37	Артикул: KIT, KIT NLA - ground connecting - Ref. 27 - 34
38	Артикул: HOUSING, HOUSING NLA - Was 6517393 - A
39	Артикул: BUSHING, BUSHING NSS - breaker plate - Was 6517394 - A
40	Артикул: 6517395, ARMATURE
41	Артикул: 6517396, SPACER bearing case
42	Артикул: 6517397, SHIELD ball bearing
43	Артикул: 6517398, CAGE bearing - W/Bearing & Retainer Ring
44	Артикул: 6517399, CAGE bearing
45	Артикул: 6517400, SPACER impulse
46	Артикул: SEAL, SEAL NSS - oil - Was 6517401 - A
47	Артикул: GASKET, GASKET NSS - impulse stop - Was 6517402 - A
48	Артикул: 6517403, PLATE impulse stop - W/Ref. 44
49	Артикул: 6517404, SLINGER oil
50	Артикул: 6517405, SCREW impulse stop plate
51	Артикул: FLANGE, FLANGE NSS - driven
52	Артикул: SPACER, SPACER NSS - driven flange
53	Артикул: ARM, ARM NSS - trip
54	Артикул: SPRING, SPRING NSS - trip arm
55	Артикул: RETAINER, RETAINER NSS - drive spring
56	Артикул: WASHER, WASHER NSS - driven flange spacer
57	Артикул: WASHER, WASHER NSS - drive cup spacing
58	Артикул: NUT, NUT NSS - impulse lock - W/Ref. 59 & 60
59	Артикул: SPRING, SPRING NSS - drive
60	Артикул: CUP, CUP NSS - drive
61	Артикул: GEAR, GEAR NLA - Drive - Was 6517355 - A
62	Артикул: WASHER, WASHER NSS - thrust
63	Артикул: RING, RING NSS - impulse lock
64	Артикул: COUPLER, COUPLER NLA - Impulse - Ref. 48-57 - Was 6517418 - A
